Package: 1 Ea
160W max
8"
woven Kevlar(R) woofer with butyl rubber surround
1"
lens-free aluminized ferro-fluid, pivoting dome tweeter
Imp: 8ohm
Sensitivity: 91dB @ 1W/1m
Freq resp: 35Hz-22kHz
High-temperature, polyimide voice coils
3rd-order electro-acoustic crossover glass epoxy PC board, low DCR inductors, tight-tolerance metalized polypropylene capacitors & gold-plated terminals
Woofer mounted in wide-mouth, foam-lined baffle with pole-mounted tweeter minimizes diffraction while widening dispersion sound field
15deg angle enables significantly enhanced cinematic sound imaging when room acoustics dictate ceiling-mounted loudspeakers for home theater systems
Dog-leg type mounting system
Acoustically transparent scrim cloth grille
Cutout dim: 11.5"
dia x 5.75"
D
Overall dia: 12.88"
Each
